Why do LEDs flicker – and how to stop it happening
WHY FLICKER LEDS?
All mains-powered light sources flicker, whether they are incandescent, gas, fluorescent, or LED, even though you might not always notice it.
In the UK, mains energy is provided as an alternating current (AC) supply with a 50 hertz frequency. This indicates that 50 times per second, the electric current that powers your lights—or any lights—switches backward and forward.
With our older incandescent lights, we weren't aware of it because the filament remained lit between flickers thanks to the bulb's residual heat. This was a byproduct of how ineffective conventional lights were. Around 90% of the energy used by these antiquated incandescent bulbs was lost as heat!
Here's how to use clear white LED tape without flickering.
So let's dispel a myth before we begin this conversation. Some people think LED flicker can be completely eliminated as long as the power input (current and voltage) stay constant because LED flicker is a result of your electricity supply.
That is untrue. Every single mains-powered light source flickers continuously.
BUT WHY DO SOME PEOPLE BELIEVE FLICKERING LEDS ARE A PROBLEM IF ALL LIGHTS FLICKER?
Flickering LEDs used to be a frequent issue. This was because LEDs lack endurance, in contrast to incandescents, halogens, and fluorescent lights. When an LED's power source is turned off, the light emission ends immediately. An LED will therefore turn on and off 50 times per second if it is connected directly to an AC mains electricity source, which is enough for it to be visible to the human eye.
In their opinion, LEDs fluctuate more than traditional light sources because of this. That used to be true in the past. But that isn't true now.
Modern LED installation initiatives don't encounter issues with LED flicker. This is due to the fact that we no longer connect the LEDs straight to the mains supply. Instead, we use an LED driver that was created specifically for powering Lights.
HOW A HIGH-QUALITY LED POWER SUPPLY CAN RESOLVE LED FLICKER: KEEPING AN EYE ON YOUR LEDS
Direct current (DC) rather than an AC power source is needed to operate LED lighting. Which is good news because the type of power source you use to drive your lights is the key to removing LED flicker.
Although the power supplies (also known as "drivers") are commonly referred to in the lighting business as "LED transformers," they are more than that. The power is not simply stepped down (transformed) by an LED driver. Additionally, it changes AC mains current to DC. Select a high-quality LED power source to give your LEDs a constant current supply. As a result, you'll get illumination that doesn't flicker.
However, a low-end, basic LED driver does not deliver a steady current. It merely changes the current's direction from AC to DC. This simplest form of power supply conversion results in an oscillating current, even though it usually doubles the frequency of the input voltage. That will produce a frequency of 100 possible flickers per second in the UK.
Of course, 100 flickers per second is much better than 50. But doesn't it still sound like a problem? Fortunately, it's rarely a problem because the human vision isn't sensitive enough to detect it. Most of us only notice light varying at speeds of 50 or less per second, which is well below the 100 flickers per second threshold. (We hardly detect the typical flickering of computer screens, which occurs between 60 and 70 hertz.)
So even though a very small minority of individuals can undoubtedly see faster strobing, it doesn't bother the majority of us. A straightforward, no-frills LED "transformer" is often all you need for project setups. Even some uses, such as oscillating bicycle lights or nightclubs, can make use of LED flicker as a desired effect.
reducing the workload
CONSTANT BRIGHTNESS + CONSTANT CURRENT
A constant-current power supply would be a great replacement for you if a straightforward LED power supply is insufficient for your project.
By varying voltage across the circuit to produce a constant electric current, these higher-spec LED drivers can essentially eradicate flicker. This minimizes the impacts of the AC/DC conversion by ensuring that the current delivered to your LEDs never fluctuates.
Even a constant-current LED driver may not be able to fully eliminate flicker in some circumstances. Before installing, make sure your LED products are compatible with the control circuits and power source you're using. One common cause of interference is problems with your control circuitry.
FLICKER AS USUAL - LISTEN TO THE WARNING!
If interference or incompatibility is the cause of your flickering LEDs, the flicker impact will be uneven. But it's possible that's not the issue you're having. It's very possible that your lights are consuming more power than your LED driver was designed to provide if they are flickering on a regular, rhythmic basis (every second, for example).
This is how high-quality LED power supplies are made; the flickering serves as a caution. If your LEDs frequently flicker, you need to upgrade to a higher-capacity power source (or several smaller ones).
Problems can also be brought on by loose cabling and other poor connections.
Your LED dimmer might be overheating if you have several electronic devices installed near to each other (on the same switchplate, for instance) (s). Intermittent flashing is most likely to result from this.
For film uses (such as TV studios, theaters, etc.), LEDs require outputs with a very high frequency and high resolution. The typical motorist cannot handle this.
MANAGEMENT OF DIMMERING
Even in an implementation of LED lighting that is otherwise flawless, dimming can lead to issues. This is due to the fact that traditional dimmers reduce the overall quantity of light output by lengthening the "off" portion of each on-off flicker cycle.
The term for this method is pulse width modulation (PWM). As long as the switching frequency doesn't fall below what the human eye can detect, PWM is very effective.
To address this issue, some makers are creating LED dimmers with a significantly shorter flicker cycle. The desired period is a thousand hertz cycle. This would mimic the approach taken by electronic ballasts, which have long fueled fluorescent lighting. However, there is a drawback: the closer your LEDs must be to your transformer, the greater the flicker frequency. Which may not always be useful.
You can easily escape the obvious flicker caused by pulse width modulation without having to install these less flexible (and more expensive) dimmers. You can avoid your LEDs' flicker cycle being obvious to the eye by simply not dimming them as low.
That frequently meant not dimming below about 50% of full brightness just a few years back. The dimmers in our current lineup, however, all give you much more freedom. You might find that there is no apparent flicker even when you dim all the way!
The tendency for zero-to-10V dimmers to flash will typically be lower than, say, a mains TRIAC control.
OVERVIEW - HOW TO FIX FLICKERING LEDS
The lighting business has embraced LEDs as an upcoming energy-efficient lighting solution over the last ten years. That's not shocking given all the benefits they provide.
You and your electrician, however, will need a fundamental comprehension of the problems underlying LED flicker in order to prevent its negative effects. So always remember the following:
1. Only ever use an LED power source made for driving LED products. Useless LED bands powered by mains AC should never be used!
2. Verify that all of your LED products are compatible with the power source and control circuits you're using.
3. Inspect the wiring for breaks in other links. Additionally, check to see if your LED dimmers are not overwhelmed.
4. Think about using an LED driver with constant power.
5. Perform tests to determine if there is a minimum dimming level below which you should not implement a dimmer system.
6. As an option to TRIAC dimming systems, think about using a zero-to-10V or digital volt-dimming system.
